REEFER CONTAINER SPECIFICATIONS
Types of Reefer Containers
Reefer containers maintain a consistent internal temperature and are equipped with ventilation and humidity control features.
20 ft Reefer Container
Ideal for small-volume shipments requiring temperature control, such as pharmaceuticals, fresh produce, and seafood.
Dimensions of 20 ft Reefer Container
• Internal Dimensions (L x W x H): 5.45m x 2.29m x 2.27m
• External Dimensions: 6.06m x 2.44m x 2.59m
• Tare Weight: Approx. 3,000 – 3,200 kg
• Max Gross Weight: 30,480 kg
• Payload Capacity: ~27,280 kg
• Volume: ~28.3 m³
• Temperature Range: -25°C to +25°C (standard); extended range available
• Power Supply: 380-460V, 3 phase, 50/60 Hz
40 ft High Cube Reefer Container
Most widely used refrigerated container in global trade. Preferred for large-scale temperature-sensitive cargo over long distances.
Dimensions of 40 ft High Cube Reefer Container
• Internal Dimensions: 11.58m x 2.29m x 2.54m
• External Dimensions: 12.19m x 2.44m x 2.90m
• Tare Weight: Approx. 4,500 – 4,800 kg
• Max Gross Weight: 34,000 kg
• Payload Capacity: ~29,500 kg
• Volume: ~67.5 m³
• Temperature Range: -30°C to +30°C
• Features: Controlled Atmosphere (CA), Fresh Air Exchange, GPS tracking options
Reefer containers comply with global standards such as ATP, ISO 1496, and CSC for food safety, temperature consistency, and structural integrity.
Reefer containers maintain a consistent internal temperature and are equipped with ventilation and humidity control features.
Types of Reefer Containers
- 20 ft Reefer Container
Ideal for small-volume shipments requiring temperature control, such as pharmaceuticals, fresh produce, and seafood.
Dimensions of 20 ft Reefer Container
• Internal Dimensions (L x W x H): 5.45m x 2.29m x 2.27m
• External Dimensions: 6.06m x 2.44m x 2.59m
• Tare Weight: Approx. 3,000 – 3,200 kg
• Max Gross Weight: 30,480 kg
• Payload Capacity: ~27,280 kg
• Volume: ~28.3 m³
• Temperature Range: -25°C to +25°C (standard); extended range available
• Power Supply: 380-460V, 3 phase, 50/60 Hz
- 40 ft High Cube Reefer Container
Most widely used refrigerated container in global trade. Preferred for large-scale temperature-sensitive cargo over long distances.
Dimensions of 40 ft High Cube Reefer Container
• Internal Dimensions: 11.58m x 2.29m x 2.54m
• External Dimensions: 12.19m x 2.44m x 2.90m
• Tare Weight: Approx. 4,500 – 4,800 kg
• Max Gross Weight: 34,000 kg
• Payload Capacity: ~29,500 kg
• Volume: ~67.5 m³
• Temperature Range: -30°C to +30°C
• Features: Controlled Atmosphere (CA), Fresh Air Exchange, GPS tracking options
Reefer containers comply with global standards such as ATP, ISO 1496, and CSC for food safety, temperature consistency, and structural integrity.
AUM Maritime, the group company of Kalash Global Logistics, is a fast-growing NVOCC based in India. We offer a wide range of equipment including ISO tanks, reefers, dry containers, and specialized units for seamless global shipping. Count on us for speed, reliability, and service excellence across every shipment.
